Overview:
LED Shoebox Area Light | Trunnion Mount | 200W/240W/300W Wattage Adjustable | 5000K Daylight | 0-10V Dimmable | IP67 Waterproof | 100-347V | 150LM/W | UL & DLC 5.1 Premium | 5-Year Warranty
- Mounting Type: Trunnion Mount
- Wattage: Adjustable (200W / 240W / 300W)
- Lumens: Up to 45,000 Lumens (150LM/W)
- Voltage: 100-347V Universal Input
- Dimming: 0-10V Dimmable
- Color Temperature: 5000K Daylight White
- IP Rating: IP67 Waterproof
- Certifications: UL Listed, DLC 5.1 Premium Qualified
- Warranty: 5 Years
Experience exceptional lighting performance with our LED Shoebox Area Light with Trunnion Mount, engineered for versatility and power. With adjustable wattage settings (200W, 240W, 300W) and high efficacy at 150 lumens per watt, this fixture is perfect for a wide range of outdoor lighting applications.
✔ Trunnion Mount for Flexible Installation
The durable trunnion bracket offers angle-adjustable mounting to walls, rooftops, and flat surfaces—ideal for billboard lighting, stadiums, parking areas, and architectural lighting.
✔ Wattage Selectable Flexibility
Adjust the output power according to project needs. Choose from 200W, 240W, or 300W for optimal brightness and energy savings.
✔ Daylight White Clarity
With a crisp 5000K color temperature, this light enhances visibility and safety in roadways, sports courts, walkways, and commercial outdoor spaces.
✔ Rugged IP67 Waterproof Construction
Built to perform in all weather conditions, this IP67-rated fixture resists water, dust, and harsh environments for reliable long-term use.
✔ Energy-Efficient & Utility Rebate Eligible
Enjoy savings with 0-10V dimming compatibility and DLC 5.1 Premium certification—perfect for rebate programs and green building compliance.
✔ UL Certified & Long-Life Performance
Designed for over 50,000 hours of operation and backed by a 5-year warranty, this LED light ensures maximum value and peace of mind.
Upgrade your commercial lighting solution with the LED Shoebox Trunnion Mount Light—offering power, precision, and performance in one durable and adjustable package.
Technical Details
Beam Angle: | 120 Degree |
Color Temprature (CCT): | 5000K |
Dimension: | 563*330*95mm |
Fixture Color: | Black |
Lifehours: | 50,000 Hours |
MPN: | HB1520 |
Warranty: | 5 Year |
Certification: | cULus, UL Listed |
CRI: | 70 CRI |
Dimmable: | 0-10V Dimmable |
IP rating: | IP65 |
Lumens: | 150LM/W |
Voltage: | AC 100-347V |
Wattage: | 200W/240W/300W |
